Overview of the Fire-Lite ANN-80 Manual
This manual provides comprehensive guidance for the Fire-Lite ANN-80 Remote Fire Annunciator, a compact, backlit LCD display designed to mimic FACP systems, ensuring easy installation and operation.
The Fire-Lite ANN-80 manual provides detailed instructions for installing, programming, and maintaining the ANN-80 Series Remote Fire Annunciators. Designed for use with compatible Fire Alarm Control Panels (FACPs), this guide covers key features, wiring connections, and troubleshooting. It also includes technical specifications, mounting options, and compatibility information. The manual ensures users can efficiently configure and operate the ANN-80 Series, which features an 80-character backlit LCD display for system status monitoring. This resource is essential for technicians and installers working with Fire-Lite systems.
Features and Benefits
Compact, backlit LCD display with 80-character capacity, mimicking FACP systems. Supports custom labels and real-time system status. Low power consumption and compatible with multiple Fire-Lite panels.
Key Features of the ANN-80 Series
The ANN-80 Series boasts a compact, backlit LCD display with 80-character capacity, mimicking the FACP display. It supports English-language text for system point status, including device type, independent point alarms, trouble conditions, and supervisory zones. Custom labels programmed into the FACP are also displayed. Designed for compatibility with Fire-Lite fire alarm control panels, these annunciators offer real-time system monitoring. Additional features include low power consumption, surface or semi-flush mounting options, and a user-friendly interface for easy operation and troubleshooting. The series includes models like ANN-80, ANN-80-W, and ANN-80C, catering to various installation needs.
Compatibility with Fire Alarm Control Panels
The ANN-80 Series is designed to work seamlessly with compatible Fire-Lite fire alarm control panels (FACPs), such as the MS-9600UDLS. It connects via the ANN-BUS communication circuit, ensuring reliable integration. The annunciator mimics the FACP display, providing consistent system status updates. This compatibility allows for centralized monitoring and control, making it an ideal solution for fire alarm systems. The series supports multiple FACP models, ensuring flexibility for various installations. Proper installation and wiring must follow FACP guidelines for optimal performance. This ensures the ANN-80 functions as an integral part of the fire alarm system.
Installation
The ANN-80 Series must be mounted in a single, double, or 4-square electrical box, with the cover attached during installation to ensure proper setup and compliance with guidelines.
Mounting the Annunciator
The Fire-Lite ANN-80 Series can be surface or semi-flush mounted in a single, double, or 4-square electrical box. To mount, open the cover by turning the key switch counterclockwise to the unlocked position. Ensure the cover remains attached to the backplate during installation, as it cannot be reattached afterward. Use the pull wire to route through the backplate’s wire channel and secure the annunciator to the electrical box or wall; This ensures proper installation and compliance with safety guidelines.
Wiring Connections
Refer to Table 1 and Figure 3 for detailed wiring connections between the ANN-80 Series and the FACP; The ANN-BUS communication circuit connects to the FACP, requiring specific wiring to ensure proper communication. Power supply requirements must be met, with the ANN-BUS rated at 5.5 VDC and 60 mA max. Wiring must comply with the FACP manual’s installation section. Ensure all connections are secure to avoid communication issues. The maximum number of ANN-BUS devices is limited, so plan accordingly to meet system requirements.
Programming and Configuration
Set DIP switches to configure unique addresses for ANN-BUS devices. Program custom labels and system status through the FACP, ensuring proper communication and display functionality.
Setting the DIP Switches
The DIP switches on the ANN-80 Series are used to set a unique address for each ANN-BUS device. DIP switches 1-4 on S1 configure the address, which is displayed as the Station ID. Ensure each device has a distinct address to avoid conflicts. The address setting is crucial for proper communication with the FACP. Refer to the FACP manual for detailed instructions on address configuration and system integration. Proper DIP switch settings ensure accurate system status and custom label displays.
Custom Labels and System Status
The ANN-80 Series supports custom labels programmed into the FACP, enhancing system clarity. It displays real-time status updates, including device type, alarms, troubles, supervisory conditions, and alarm silences. The backlit LCD ensures visibility in low-light environments, while the 80-character display provides detailed information. Custom labels allow for tailored system monitoring, making it easier to identify specific points and zones. This feature ensures quick response to system events, optimizing fire safety management and operational efficiency.
Maintenance and Troubleshooting
Perform regular maintenance checks and address common issues promptly to ensure reliable operation of the Fire-Lite ANN-80 annunciator system.
Regular Maintenance
Regular maintenance ensures optimal performance of the Fire-Lite ANN-80. Clean the LCD display with a soft cloth and avoid harsh chemicals. Inspect wiring connections for tightness and wear. Verify that the annunciator is securely mounted and the cover remains attached to the backplate. Check for firmware updates and refer to the FACP manual for additional guidance. Perform these tasks periodically to prevent issues and maintain reliable system operation.
Troubleshooting Common Issues
Identify symptoms of malfunctions, such as blank displays or incorrect status messages. Check wiring connections for looseness or damage, ensuring proper alignment with FACP terminals. Verify DIP switch settings match the FACP configuration. If the display flickers, inspect the power supply and ensure it meets voltage requirements. For communication errors, confirm the ANN-BUS address is unique and correctly set. Refer to the manual for detailed diagnostic procedures and solutions to restore proper functionality.
Compatibility
The Fire-Lite ANN-80 series is designed to work seamlessly with Fire-Lite fire alarm control panels, including the MS-9600 and MS-9200UDLS systems, ensuring reliable performance across compatible setups.
Supported Fire-Lite Systems
The Fire-Lite ANN-80 series is compatible with various Fire-Lite fire alarm control panels, including the MS-9600UDLS, MS-9200UDLS, and other compatible FACP systems. This ensures seamless integration and reliable communication, allowing the ANN-80 to accurately mimic the FACP display and provide real-time system status updates. Compatibility extends to multiple configurations, making the ANN-80 a versatile solution for different fire alarm setups, while maintaining consistent performance across all supported systems.
Technical Specifications
The Fire-Lite ANN-80 operates on 18.8VDC to 38.2VDC, with a standby current of 39 mA, featuring an 80-character backlit LCD display suitable for fire alarm systems.
Operating Voltage and Power Requirements
The Fire-Lite ANN-80 Series operates on a voltage range of 18.8VDC to 38.2VDC, with a standby current of 39 mA. The ANN-BUS communication circuit is rated at 5.5 VDC, supporting a maximum current of 60 mA. The device is designed for efficient power consumption, ensuring reliability in fire alarm systems. Surface or semi-flush mounting options are available, compatible with single, double, or 4-square electrical boxes. The cover must remain attached during installation to maintain integrity and functionality.
Display and Mounting Options
The Fire-Lite ANN-80 features an 80-character backlit LCD display, ensuring clear visibility of system status and custom labels. It supports surface or semi-flush mounting in single, double, or 4-square electrical boxes. The optional ANN-SB80KIT provides additional backbox solutions for flexible installation. The cover must remain attached during mounting to maintain integrity. This design offers versatility for various installation environments, ensuring reliable operation and easy integration with compatible fire alarm systems.
Wiring and Connections
The ANN-80 connects via the ANN-BUS communication circuit, supporting up to 8 devices. Wiring must follow FACP guidelines, ensuring proper power supply and signal transmission.
ANN-BUS Communication
The ANN-80 Series communicates via the ANN-BUS circuit, enabling connection to compatible FACPs. It supports up to 8 devices on the ANN-BUS, with each requiring a unique address set via DIP switches. The ANN-BUS operates at 5.5 VDC, with a maximum current of 60 mA. If the number of devices exceeds the FACP’s power capacity, an auxiliary power supply may be required. Proper wiring and addressing ensure reliable communication and accurate system status display. Refer to the FACP manual for detailed wiring instructions and power requirements.
Power Supply Requirements
The ANN-80 Series operates within an 18.8VDC to 38.2VDC voltage range, with a standby current of 39 mA and a maximum of 125 mA under full load (including backlight). The ANN-BUS circuit is rated at 5.5 VDC with a maximum current of 60 mA. If the total power requirements exceed the FACP’s capacity, an auxiliary power supply must be used. Ensure all connections meet the specified voltage and current ratings to maintain reliable operation and avoid damage to the system. Refer to the FACP manual for detailed power supply specifications and recommendations.
